RUGGED GNSS RTK TABLET PC
8 Inch High Precision GNSS /RTK/GIS Mobile Platfrom
| Model | HUGEROCK G80N | HUGEROCK G80F | HUGEROCK G80M |
|---|---|---|---|
| Characteristics | Multi-satellite single frequency Meter-level RTD | Multi-satellite dual frequency Centimeter level RTK | Multi-satellite multi-frequency omnidirectional, MM-level RTK |
| Display | 8", 1200×1920, 1000 cd/m2, IPS | 8", 1200×1920, 1000 cd/m2, IPS | 8", 1200×1920, 1000 cd/m2, IPS |
| CPU | Cortex A73, Octa-core, 2,0 GHz | Cortex A73, Octa-core, 2,0 GHz | Cortex A73, Octa-core, 2,0 GHz |
| RAM / ROM | 8 GB / 128 GB | 8 GB / 128 GB | 8 GB / 128 GB |
| Camera | 13 Mpx (AF), flash / 5 MP | 13 Mpx (AF), flash / 5 MP | 13 Mpx (AF), flash / 5 MP |
| Battery | 18 900 mAh | 18 900 mAh | 18 900 mAh |
| SIM | 2× nano SIM | 2× nano SIM | 2× nano SIM |
| TF card | MicroSD, max 256 GB | MicroSD, max 256 GB | MicroSD, max 256 GB |
| Ports | 1× 3,5mm audio, 1× Type-C (charging) 1× Type-C (OTG) | 1× 3,5mm audio,
1× Type-C (charging) 1× Type-C (OTG) | 1× 3,5mm audio,
1× Type-C (charging) 1× Type-C (OTG) |
| Sensors | Proximity Gravity Magnetic field Motion Rotation vector Light Acceleration Temperature (optional) Pressure (optional) | Proximity
Gravity Magnetic field Motion Rotation vector Light Acceleration Temperature (optional) Pressure (optional) | Proximity
Gravity Magnetic field Motion Rotation vector Light Acceleration Temperature (optional) Pressure (optional) |
| Charger | 5.0 V, 2A-10W | 5.0 V, 2A-10W | 5.0 V, 2A-10W |
| Navigation | GPS, Beidou, Glonass, AGPS, SBAS (EPO 2.5m) | GPS, Beidou, Glonass,
AGPS, SBAS (EPO 2.5m) | GPS, Beidou, Glonass,
AGPS, SBAS (EPO 2.5m) |
| Phone call | GSM /WCDMA/CDMA 1X/VoLTE | GSM /WCDMA/CDMA 1X/VoLTE | GSM /WCDMA/CDMA 1X/VoLTE |
| Data connection | 2G, 3G, 4G Wi-Fi 802.11 a/b/g/n/ac BlueTooth 5.0 LE | 2G, 3G, 4G
Wi-Fi 802.11 a/b/g/n/ac BlueTooth 5.0 LE | 2G, 3G, 4G
Wi-Fi 802.11 a/b/g/n/ac BlueTooth 5.0 LE |
| IP | IP67 | IP67 | IP67 |
| Shake-proof | 1-19Hz/1.0mm, 19-200Hz/1.0g | 1-19Hz/1.0mm, 19-200Hz/1.0g | 1-19Hz/1.0mm, 19-200Hz/1.0g |
| Dropproof /IK | MIL-STD-810G/Method516.6/ Procedure IV & Touch Panel IK05 | MIL-STD-810G/Method516.6/
Procedure IV & Touch Panel IK05 | MIL-STD-810G/Method516.6/
Procedure IV & Touch Panel IK05 |
| Reliability | MTBF>5000h, MTTR<0.5h | MTBF>5000h, MTTR<0.5h | MTBF>5000h, MTTR<0.5h |
| Operating Temperature | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C |
| Certification | 3C/FCC/CE/ROHS/IP67(IEC 60529) | 3C/FCC/CE/ROHS/IP67(IEC 60529) | 3C/FCC/CE/ROHS/IP67(IEC 60529) |
| Size | 256 × 159 × 23 mm | 256 × 159 × 23 mm | 256 × 159 × 23 mm |
| Weight | 1015 g | 1015 g | 1015 g |
| Operating system | Android 11 | Android 11 | Android 11 |
| Package | USB cable/Charger 5V 2A/ Introduction manual/ Screen protector/ Packing box/Aircraft box/ Toolkit(optional)/OTG x 1/ SIM Card Ejector x 1 | USB cable/Charger 5V 2A/
Introduction manual/ Screen protector/ Packing box/Aircraft box/ Toolkit(optional)/OTG x 1/ SIM Card Ejector x 1 | USB cable/Charger 5V 2A/
Introduction manual/ Screen protector/ Packing box/Aircraft box/ Toolkit(optional)/OTG x 1/ SIM Card Ejector x 1 |
| Antenna | Multi-satellite single frequency | Multi-satellite dual frequency | Multi-satellite multi-frequency omnidirectional |
| Antenna frequency | BDS B1; GPS L1; GLONASS G1; GALILEO E1 | BDS B1/B2/B3; GPS L1/L2; GLONASS G1/G2; GALILEO E1/E5b | BDS B1/B2/B3; GPS L1/L2; GLONASS G1/G2; GALILEO E1/E5b |
| Installation Method | SMA | SMA | SMA 90 degree omnidirectional |
| Max channels | 92 | 184 | 1408 channels, based on NebulasIV |
| Single-point positioning accuracy | 1.5 m CEP (with SBAS); 2.0 m CEP (without SBAS) | 0.8m CEP | P:1.5m E: 2.5m CEP (with SBAS) |
| RTD Accuracy | 1.5 m CEP (with RTD) | ≤ 10mm + 1 ppm CEP | P:0.8cm + 1 ppm CEP E:1.5cm + 1 ppm CEP |
| Nav. Update Rate | 1- 25 Hz | 1- 20 Hz | 20 Hz |
| Start | 24 s (cold), 2 s (hot), 2 x (aided) | 24 s (cold), 2 s (hot), 2 x (aided) | <30 s (cold), <20 s (hot), <1 s (aided) |
| Cors data | RTCM 3.3 | RTCM v. 3.3, SPARTN v. 2.0 | RTCM 3.3 |
| Data format | NMEA 4.10, UBX binary, RTCM 3.3 | NMEA, UBX binary, RTCM v. 3.3, SPARTN v. 2.0 | NMEA-0183，Unicore |
| Inertial navigation | none | none | none |
